Benefits of polyurethane foam
Unique aluminium grease filters are enhanced with a special polyurethane foam that eliminates up to 98% of all grease particles and other impurities. At the same time, the hood maintains its absorption efficiency.
Shiny and fingerprint-free finish
All stainless steel surfaces are coated with a special TouchFree film that prevents fingerprint markings, leaving the surface always shiny and making cleaning much easier.
See what you're cooking
LED lighting provides excellent and highly efficient illumination of the cooking hob and represents an important aesthetic and functional element in the kitchen. Its useful life is thirty times as long as that of conventional light bulbs, and it saves up to ten times as much power.
Energy class
B
Venting tube diameter
15 cm
Colour of housing/chimney
stainless steel / stainless steel
Lightning efficiency class
A
Material of housing/chimney
stainless steel / stainless steel
Fluid dynamic efficiency class
B
Grease filtering efficiency class
A
Air flow by extraction version, step 1
230 m³/h
Air flow by extraction version, step 2
372 m³/h
Air flow by extraction version, step 3
505 m³/h
Maximum extraction rate by extraction operation
505 m³/h
Maximum extraction rate by recirculation operation
380 m³/h
Lamp type
LED
Control setting
Button control
Power of lights
6 W
Number of lights
2
Number of speed positions
3
Height
250 mm
EAN code
3838942137013
Motor type
Capacitor motor
Net weight
8.6 kg
Gross weight
11.2 kg
Product code
565738
Connected load
141 W
Filter material
Washable aluminium with polyurethane foam
Max. noise level
62 dB(A)re 1 pW
Number of motors
1
Number of filters
2
Dimensions (W×H×D)
60 × 25 × 50 cm
No return airflow flap
150 mm
Nominal current of fuse
10 amp
Annual energy consumption
62.2 kWh
Max. height of the chimney
875 mm
Min. height of the chimney
545 mm
Dimensions of packed product (W×H×D)
64.5 × 63.7 × 36.5 cm
Coal filter code (optional as separate purchase)
315275
